Secure and Reliable MIL-DTL-26482 Series I Connector.MS3114E8-4S.4 Female Pins. Jam Nut Receptacle.Olive Green Cadmium
Part Number:MS3114E8-4S
Product Description:
MIL-DTL-26482 Series I is a miniature connector designed to meet the rigorous requirements of military applications. It features a jam nut receptacle with an olive green cadmium finish and an aluminum alloy coupling nut. This Series I connector is available in shell size 08 and is designed to provide superior environmental protection and reliable electrical performance. The MIL-DTL-26482 Series I is ideal for applications in harsh and extreme environments, ensuring secure and dependable connections.
Features:
- Product Name: MIL-DTL-26482 Series Ⅰ
- Coupling Nut Material: Aluminum Alloy
- Number of Contacts: 4
- Shell Finish: Cadmium Olive Drab
- Gender: Receptacle
- Jam Nut Receptacle
- Current Rating: 7.5 A
Technical Parameters:
| Description | Specification |
| Product Name | MIL-DTL-26482 Series Ⅰ |
| Shell Size | 08 |
| Gender | Receptacle |
| Number of Contacts | 4 |
| Shell Material | Aluminum Alloy |
| Shell Finish | Cadmium Olive Drab |
| Voltage Rating | 500V |
| Coupling Nut Material | Aluminum Alloy |
| Contact Termination | Crimp |
| Current Rating | 7.5 A |
Product Pictures
Applications:
KAIDA MS3114E8-4S Receptacle Connector from China is an ideal product for a wide range of applications. It is made of high quality aluminum alloy with olive drab cadmium, ensuring its superior strength and durability. This MIL-DTL-26482 Series I connector is specifically designed to provide a secure connection with a voltage rating of 500V. It is equipped with crimp contact termination and meets the high-performance standards of the industry. This reliable receptacle connector is perfect for rugged and harsh environments and is guaranteed to provide a strong and reliable connection.
Customization:
KAIDA MS3114E8-4S Jam Nut Receptacle, MIL-DTL-26482 Series Ⅰ - Place of Origin: China
- Number of Contacts: 4
- Contact Termination: Crimp
- Current Rating: 7.5 A
- Coupling Nut Material: Aluminum Alloy
- Shell Material: Aluminum Alloy
- Olive Drab cadmium plated per MIL-DTL-13924
Support and Services:
MIL-DTL-26482 Series Ⅰ Technical Support and Service
- On-site personnel training on installation, operation, and maintenance
- 24/7 technical support over the phone, email, and web
- On-site troubleshooting and repair
- Access to technical documents and software updates
- Factory-certified parts and components
Packing and Shipping:
MIL-DTL-26482 Series Ⅰ Packaging and Shipping:
- Each product must be packaged in accordance with MIL-STD-2073-1.
- The product must be shipped in accordance with MIL-STD-129P.
- The product must be labeled with the MIL-STD-129P labeling requirements.
- The product must be shipped in accordance with MIL-STD-130U.
- The product must be labeled with the MIL-STD-130U marking requirements.
FAQ:
- Q: What is MIL-DTL-26482 Series Ⅰ?
- A: MIL-DTL-26482 Series Ⅰ is a waterproof and dustproof circular connector, manufactured by KAIDA and model MS3114E8-4S. It is made in China.
- Q: What are the features of MIL-DTL-26482 Series Ⅰ?
- A: MIL-DTL-26482 Series Ⅰ has a shell made from aluminium and is thermoplastic elastomer sealed, which makes it resistant to dust and water. It also has an operating temperature range of -55℃ to +125℃ and a current rating up to 6A.
- Q: What is the application of MIL-DTL-26482 Series Ⅰ?
- A: MIL-DTL-26482 Series Ⅰ is a widely used in military, aerospace, communications, medical, industrial and other fields.
- Q: What is the advantage of MIL-DTL-26482 Series Ⅰ?
- A: MIL-DTL-26482 Series Ⅰ has a reliable connection, good electrical performance and high durability.
- Q: What is the certification of MIL-DTL-26482 Series Ⅰ?
- A: MIL-DTL-26482 Series Ⅰ has obtained UL certification.
-
- MIL-C-26482 Series 1 Datasheet.pdf
